AWD: The Impreza WRX STI uses Driver Controlled Center Differential (DCCD), the most performance-directed type of Symmetrical AWD. A limited-slip, planetary gear-type center differential provides a performanceoriented 35:65 front/rear power split.
AWD: The Impreza WRX STI uses Driver Controlled Center Differential (DCCD), the most performance-directed type of Symmetrical AWD. A limited-slip, planetary gear-type center differential provides a performanceoriented 35:65 front/rear power split.
LSD: Advantages of mechanical LSD
The mechanical LSD mechanism is advantageous in that it has good response of the LSD differential limiting force to the engine driving force and has direct vehicle operational stability allowing the driver to easily grasp changes in the vehicle behavior. This post discusses these advantages in comparison with conventional DCCD system.
The Driver’s Control Center Differential system is system that appropriately controls the differential limiting force of center differential LSD depending on running conditions of a vehicle. The DCCD system evolved provides controls that follow operations of the driver, while conventional DCCD system provides those based on conditions of the vehicle.
The system consists of a center differential of planetary gear type provided with LSD function, a steering angle sensor, a yaw rate sensor, a lateral G sensor, a DCCD control module and other components.
Hybrid LSD mechanism using conventional electromagnetic clutch LSD mechanism added with torque-sensitive mechanical LSD mechanism allows approximate coincidence between the vehicle acceleration/deceleration and LSD clutch differential limiting timings, resulting in linear LSD characteristics acquired through driver’s accelerator operation. Thus, the driver can more freely control the vehicle by easily grasping behavior of the vehicle.
In addition, the steering angle sensor let the DCCD control module know the driver’s intension of turning. In combination with the yaw rate and lateral G sensors, it adjusts the electromagnetic clutch LSD differential limiting force based on the running path imaged by the driver and the actual behavior of the vehicle. Thus, cornering in better accordance with the driver’s image is enabled, preventing occurrence of understeer and oversteer.
For balancing between the vehicle turning performance and traction during turning in a high order, the center differential driving torque is set to have distribution ratio 41:59.
Manual mode switch/DCCD control dial
In manual mode, the DCCD control can be used to adjust the differential limiting force of the electromagnetic clutch LSD mechanism in the range from free to lock. Current settings of the control dial are displayed on the indicator in the meter.
The 2008 Subaru Impreza WRX STI has a heritage of power and control. Previous models have been the foundations for countless racing victories and championships. The new WRX STI promises the same with it’s 305- horsepower, turbocharged, intercooled Boxer engine and a six-speed manual transmission.
Power and control incorporate enhanced technology. As suggested by new switchgear on the dashboard and center console and my markings within the instrument cluster’s center-mounted tachometer, a driver has some things to learn before wringing out the most from the car.
Today’s electronics now allow the driver to tinker with engine response characteristics, the manner in which All-Wheel-Drive system fights for traction, and the degree to which braking and engine management help maintain vehicle stability. These capabilities are made possible by standard Vehicle Dynamics Control (VDC), Driver Controlled Center Differential (DCCD), and Subaru Intelligent Drive (SI-Drive).
Prior to the Legacy RS turbo, Subaru had never enjoyed the experience of distributing a genuine performance car. Of course, there had been the 4WD turbo RX and Vortex, but neither could crack 10 seconds for the 0-100km/h sprint – although they were very reliable. The RS was the gun version of the first Legacy series released in 1988 and discontinued in 1994. The RS (Rally Sport) model was aimed squarely at world rallying, with many of its components and concepts carried over to the dominating Impreza WRX.
The center Viscous LSD on the MT models initially starts out with a 50/50 torque split, front and rear, and will up the ratio towards the end with more traction. The manufacturer doesn’t give a final figure, so the max split is either 65/35, or could even venture as high as 95/5, since the A/T model has a different system that is marketed at a 65/35 maximum split. A higher ratio would explain some of the handling characteristics at the limit. The rear differential is also a Viscous LSD model.
The BC/BF is unique in having an Air – Water intercooler with a front mounted radiator for optimal cooling. The bonnet scoop only provides cooling to the turbo. While later model legacy’s have all used air to air intercoolers.
In June 1995, to celebrate their winning of both the manufacturers and drivers World Rally Championship titles, Subaru in the UK released a limited edition run of two hundred cars (numbered 1 to 201 – no number 13!) prepared by Prodrive going by the name of the Series McRae. The main improvements over the standard model are:
On the road price was £22,999
Next page will be the Catalunya edition!
